Glass Greenhouse
Glass Greenhouse Design: Dutch Venlo structure, high intensity and long service life Well-sealed aluminum gutters and profiles design,Stable structure, strong resistance to wind and snow 400g/m2 Zinc coat, Hot SENDZIMIR galvanized treatment Over 90% Light transmission, special fit for cold, less sunshine area and for R&D center No Item Specification 1 Span Size 8/9.6/12m 2 Bay size 3.2/4m 3 Section 4/4.5/5 4 Gutter height 3-8m 5 Cover Materials Single or double layers, 4/5mm thickness float or tempered glass, 6 Ventilation single roof vents or double roof vents, motor drive Sketch Map:
Message
Product Description
Glass Greenhouse
Design:
- Dutch Venlo structure, high intensity and long service life
- Well-sealed aluminum gutters and profiles design,Stable structure, strong resistance to wind and snow
- 400g/m2 Zinc coat, Hot SENDZIMIR galvanized treatment
- Over 90% Light transmission, special fit for cold, less sunshine area and for R&D center
| No | Item | Specification |
|---|---|---|
| 1 | Span Size | 8/9.6/12m |
| 2 | Bay size | 3.2/4m |
| 3 | Section | 4/4.5/5 |
| 4 | Gutter height | 3-8m |
| 5 | Cover Materials |
Single or double layers, 4/5mm thickness float or tempered glass, |
| 6 | Ventilation |
single roof vents or double roof vents, motor drive |
Sketch Map:
